Efficient Screw Configuration for Aquafeed Floatability Control

A principal advantage of using extrusion cooking to make aquafeeds is that it permits sinking and floating diets to be produced on the same equipment.

Generally, floating feed, floating on the surface of the water, enables aqua farmers to observe fish and monitor their health and vigor, also avoids wasted feed and pond pollution problems, in comparison with sinking pellets which have shorter water stability time, and will gradually sink and settle on the bottom if uneaten.

Since different feeding habits of the particular species of fish, to produce pellets of various floating or sinking characteristics is preferred by feed machine manufacturers for meeting market need. And the application of advanced extrusion technology correctly enables the production of feed with desired density and sinking speed according to manufacturers’ pecific needs. Since single-screw cooking extruders are widely employed in dry, expanded, aquafeed industry, this article will discuss how to change screw configuration to maximize floating feed and sinking feed processing performances.

There is a misunderstanding for some users unfamiliar with extruder that oil-rich floating feed and sinking feed can be produced on the same extruder without changing any equipment configuration. In fact, the extruder screw configuration delivered by manufacturer is relatively neutral which means both floating and sinking feed can be produced but not under optimal condition. Therefore, in actual production, at given raw material formula, if the following two phenomena (some sinking feed generated during the production of floating feed or some floating feed generated during the production of sinking feed) occur during production, the screw pitch, screw flight profile, number of flights, root diameter (i.e., flight depth), and cut flights can be varied to permit optimization of the extruder screw configu-ration for obtaining ideal and uniform floating or sinking characteristics.

Congurations for oating auqafeeds

If some sinking feed is generated during the production of floating feed, the following measures can be took for troubleshooting:
1.Replace the die plate. Die plate of smaller opening area is recommended to adopt to increase the pressure of extruding chamber and the floating probability instead of plugging the die hole;
2.Replace the discharging screw with three-grooved screw to improve the floating rate;
3.Change the assembly mode of kneading elements. It is recommended to make all the kneading elements arranged to feed reverse among which three kneading elements were arranged to feed forward and three to feed reverse when leaving factory;
4.Replace the middle section screw with three-grooved screw or short doublethreaded screw head combined with kneading elements.

Generally, case 2 and case 3 are conventional screw configurations for the main production of floating feed; only when the first three methods mentioned above have no effect can configuration 4 be applied, which is mainly used for processing some unconventional formulas, such as the formula with high fat and low starch. For example, configuration 4 once was successfully employed on FAMSUN MY165 to produce floating feed with fat content of 11% and starch content of over 20%, the raw materials are vegetable based, and the fat mainly including fish oil and vegetable oil is added in mixer.

******
FAMSUN is an integrated solution provider of plants, equipment and services in the farm-to-table industry chain. Our global ability and experience in turnkey project delivery in the fields of feed milling, grain logistics and processing, steel structure building as well as industrial automation has helped our customers succeed in their respective markets.
