Technical features of DC180

Average Customer Rating
rating
(0 Review)
Brand:
MUYANG
Type:
DC180
Engine power(ph):
54
  • Overview
  • Customer Review
  • Purchasing guide
  • Service Guarantee
页眉

    Technical features of DC180



Brand:MUYANG


Technical features of DC180:

Pendular ring-driven sickle;

Double-layer vibrating screen in cleaning system;

Quadruple belt drive;

Reinforced hydraulic steering drive axle;

400×90×48 rubber track;

Re-threshing;

Adjustable cylinder bar teeth, adjustable threshing clearance.



Parameter Items

Parameter Value

Engine power(ps)

54

Cutting width(mm)

1800

Feeding in volume (kg/s)

1.5

Total loss rate(%)

Wheat≤1.5 rice≤3.5

Broken rate (%)

Wheat≤2.0 Rice≤2.0

Impurity rate (%)

Wheat≤2.0 Rice≤2.0

Threshing and cleaning structure

Single horizontal axis flow roller

Gravure plate adjustable structure

Increase the adjustment pads

and adjust the position of threshing

Axis-flow roller

(outer diameter×length))(mm)

¢550×1265

Grain tank capacity(m3 )

0.4/0.6

Grain Unloading

manual receiving grain

Caterpillar specification

400×90×48

Running speed range

1.1~8.29(hydraulic) 1.54~8.56(mechanic)

Operating weight (kg)

(2360、2600、2800)±5%

Overall Dimensions (L*W*H mm)

≤5600×2100×2600
