Home >> Machinery Spare Parts >> For Grinder >> SFSP Series >> Rotor ( SFSP 112*80E )(60Hz)
SKU: 5074E589994AE

Rotor ( SFSP 112*80E )(60Hz)

Please select the accessories in the table below, referring to the structure diagram. The price in this page is unofficial virtual price. The accurate price will be offered after you place orders.

Average Customer Rating
rating
(0 Review)
add to inquiry basket
NO. ITEM ADVISE
QTY
PRICE QTY
1 Main shaft 1 $0.00 - +
2 End cover 1 $0.00 - +
3 Bearing pedestal 2 $0.00 - +
4 Round nut 100 2 $0.00 - +
5 Gasket 100 2 $0.00 - +
6 Bearing 2 $0.00 - +
7 Oil seal 3 $0.00 - +
8 Round nut 140 2 $0.00 - +
9 Gasket 140 2 $0.00 - +
10 Outer plate of hammer supporting frame 2 $0.00 - +
11 Spacer of main shaft 8 $0.00 - +
12 Pin shaft 4 $0.00 - +
13 Spacer I 8 $0.00 - +
14 Spacer II 8 $0.00 - +
15 Spacer III 34 $0.00 - +
16 Spacer IV 23 $0.00 - +
17 Spacer V 12 $0.00 - +
18 Hammer 84 $0.00 - +
19 Inner plate of hammer supporting frame 7 $0.00 - +
20 Screw shaft 8 $0.00 - +
21 Spacer of hammer supporting frame 64 $0.00 - +
22 Holding ring 2 $0.00 - +
23 Bush 1 $0.00 - +
24 Key C22×165 1 $0.00 - +
Replacement Total:
  • Overview
  • Customer Review
  • Delivery
  • Purchasing guide

Rotor of hammer mill SFSP 112*80E(60Hz)



Structure diagram of rotor



List of rotor

No.

Name

Quantity(pcs/unit)

1

Main shaft

1

2

End cover

1

3

Bearing pedestal

2

4

Round nut 100

2

5

Gasket 100

2

6

Bearing

2

7

Oil seal

3

8

Round nut 140

2

9

Gasket 140

2

10

Outer plate of hammer supporting frame

2

11

Spacer of main shaft

8

12

Pin shaft

4

13

Spacer I

8

14

Spacer II

8

15

Spacer III

34

16

Spacer IV

23

17

Spacer V

12

18

Hammer

84

19

Inner plate of hammer supporting frame

7

20

Screw shaft

8

21

Spacer of hammer supporting frame

64

22

Holding ring

2

23

Bush

1

24

Key C22×165

1
