Rotor of pellet mill [MUZL1200(SZLH650*175)]
Structure diagram of rotor assembly
List of rotor assembly
No. |
Designation |
Qty(pcs/unit) |
1 |
Scraper |
1 |
2 |
Main shaft disc |
1 |
3 |
Assembly of main shaft |
1 |
4 |
Sealing cover |
1 |
5 |
Locknut of press roller |
1 |
6 |
Roller supporting shaft |
1 |
7 |
Driving flange of the ring die B |
1 |
8 |
Bolt M24×130 |
1 |
9 |
Driving flange of the ring die A |
1 |
10 |
Screw M24×100 |
1 |
11 |
Rotor |
1 |
12 |
Bearing at the front end |
1 |
13 |
Bearing spacer |
1 |
14 |
Big belt pulley |
1 |
15 |
Bearing at the rear end |
1 |
16 |
Bolt M16×150 |
1 |
17 |
Sealing cover at the rear end |
1 |
18 |
Oil seal at the rear end |
1 |
19 |
Inner race (Ⅱ) |
1 |
20 |
Locknut |
1 |
21 |
Inner race(Ⅰ) |
1 |
22 |
Oil seal at the front end |
1 |
23 |
Seal ring at the front end |
1 |
24 |
Centering pin of ring die |
1 |
25 |
Nut M24 |
1 |
