Brand:FUTIAN
Embreagem LUK alemã, alta confiabilidade;
TD750H com folga de 855 mm, para atender a demanda de elevada altura ao solo.
Parameter Items |
Parameter Value |
Model |
TD750H |
Maximum power of PTO shaft |
49.5 kW |
Dimension |
|
Length (including rear suspension) |
4158 mm |
Width |
2610 mm |
Height (to the top of muffler) |
3134 mm |
Wheelbase |
2366 mm |
Track base |
|
Front wheel |
2360 mm |
Rear wheel |
2280 mm |
Structure mass |
3550(with cab) kg |
Minimum working mass |
4090(with cab) kg |
Minimum turning radius |
4300±300(single side brake)/4900±300(Non-single side brake)mm |
Engine |
|
Model |
1004-4T |
Type |
Inline, water cooling, 4-stroke |
Number of cylinder |
4 |
Cylinder diameter×stroke (mm) |
100×127 |
Displacement |
4 L |
Rated power |
55 .0 kW |
Rated rotary speed |
2300 r/min |
Max. torque/rotary speed |
288/1500~1700 Nm/r/min |
Transmission/Drive |
|
Clutch model |
Single plate, dry, double action clutch/ |
Gear |
8+4/16+8 Creeping gear/ Shuttle gear、8+8 Shuttle gear |
Differential lock |
Four planets, close type |
Running speed |
|
8F+4R |
Forward:2.41/2.44—36.37/36.80Reverse:3.24/3.28—11.25/11.38 Km/h |
16F+8R Creeping gear |
Forward:0.48/0.49—36.37/36.80Reverse:0.65/0.66—11.25/11.38 Km/h |
16F+8R Shuttle gear |
Forward:1.58—33.69Reverse:2.41—10.33 Km/h |
Hydraulic system |
|
Type |
Open-centered, split type/semi-split type |
Hydraulic output valve |
Single hydraulic output or multi-way valve |
System pressure |
18 MPa |
3-point suspension |
Three-point rear suspension, category II |
Regulating method |
Semi-split lifter: draft and positional mixed regulation, float control |
Maximum lifting capacityat 610mm behind suspending point |
≥15(Semi-split lifter )/≥25(split lifter) KN |
Steering type |
Front wheel hydraulic steering |
PTO shaft –Rear |
|
Type |
rear independent type |
Specification |
φ35,6/φ38,8/φ35,21 |
Rotary speed |
540/1000 r/min |
Traction /towing |
|
Traction device |
|
Type |
Swing link type |
Distance to the ground |
690 mm |
Towing device |
U type hook |
Tyrespecification |
|
Standard: front wheel /rear wheel |
9.5-32/ 12-38 |
Filling capacity |
|
Engine radiator |
14 L |
Fuel tank |
145 L |
Engine oil pan |
17 L |
Hydraulic and steering oil |
2.5 L |
Oil for transmission system |
38 L |
